As a leading HVAC solutions provider, Klima Global is your trusted Fan-Coil Unit supplier across the GCC, including the UAE, Saudi Arabia (KSA), Oman, Qatar, Kuwait, and Bahrain. We specialize in high-efficiency climate control, offering the TAITECH TALD series—a premier Low static pressure FCU designed for discreet, high-performance cooling and heating in demanding environments.
Product Overview: TALD Low Static Pressure FCU
The TALD series is an ultra-low profile Fan-Coil Unit engineered specifically for commercial applications where ceiling space is at a premium. With a height of just 245mm or 295mm, this Low static pressure FCU integrates seamlessly into the shallow ceiling voids common in luxury hotels and modern office complexes across the Middle East.
Whether you are retrofitting a hospitality project in Dubai or designing a new corporate hub in Riyadh, our Low static pressure FCU provides the perfect balance of quiet operation and powerful thermal performance.
Key Performance Features
- Extra-Flat Design: A compact profile of 245mm or 295mm allows for maximum ceiling height in architectural designs.
- Precision Airflow: Airflow ranges from 340 to 3400 m³/h, ensuring rapid climate stabilization.
- Versatile Static Pressure: Available pressure ranges from 0 to 50 Pa, optimized for localized ducted applications.
- Energy Efficient Motors: Options for both AC and DC motors are available to meet the stringent energy regulations of the UAE and KSA.
- High-Quality Heat Exchangers: Features 3/8″ (9.52mm) refrigeration-quality copper tubes with corrugated aluminum blue fins for superior heat transfer.
- Customizable Pressure: This Low static pressure FCU offers available pressure ranging from 0 to 50 Pa to suit various ducting needs.
- Ultra-Slim Profile: Features an extra-flat design with a height of only 245mm or 295mm, perfect for restricted ceiling voids.
- Durable Casing Options: An optional double-skin casing is available for enhanced thermal and acoustic performance.
- Flexible Motor Technology: Both AC and DC motors are available to meet specific energy efficiency requirements across the GCC.
High-Volume Airflow: Available in two primary sizes with maximum flows of 2380 m³/h (Size 1) and 3400 m³/h (Size 2).
Versatile Configurations: Choose from three distinct versions to match your project’s piping:
2 tubes + 3 rows (Standard configuration).
2 tubes + 4 rows.
4 tubes + 3+1 rows.
- Commercial Comfort: The TALD Low static pressure FCU is specifically designed for high-end commercial buildings.
- Hospitality & Corporate: Optimized for hotel rooms and offices, providing reliable cooling and heating for guests and professionals.
Structure
Built to Last: Fabricated with a galvanized steel casing featuring corner-reinforced hanging holes.
Secure Installation: Uses M8 nuts crimped directly into the structure for safe suspension.
Corrosion Resistance: Optional RAL color powder coating is available to protect against high humidity and rust.
Premium Double-Skin: The optional double-skin features a 0.5mm pre-painted outer layer, a 0.5mm inner layer, and 40kg/m³ density PE insulation (25mm total thickness).
Fan & Motor Assembly
Efficient Fan Design: Utilizes forward-curved centrifugal, double-inlet fans with direct drive for consistent performance.
Easy Maintenance: Quick access to the fan and filter is provided via a dedicated access door.
Safe Motor Operation: Features a built-in single-phase IP20 motor equipped with thermal protection.
Advanced DC Option: For superior control, a DC Motor is available across the range.
Heat Exchanger & Filtration
Quality Materials: Built with 3/8″ (9.52mm) refrigeration-quality copper tubes and 3/4″ male connections.
Precision Fins: Aluminum blades are mechanically crimped for maximum heat transfer efficiency.
Field Versatility: Units are mounted on slides, making them interchangeable on-site.
Rigorous Testing: Every Fan-Coil Unit undergoes a 100% coil leakage test at 350 PSI.
Effective Filtration: Comes standard with a G4 nylon filter in an 8mm aluminum frame, with 12.5mm and 25mm thicknesses also available.
Sea Freight Ready: Units are individually packed in cartons of FCL sea-shipment quality.
Secure Global Transit: For LCL or air shipments, Klima Global provides extra pallets featuring corner protection and forklift gaps for safe handling.
Performance Range: Airflow spans from 340 to 3400 m³/h with a cooling capacity between 1.5 kW and 11 kW (sensible at medium speed).
International Standards: Project selection software is compatible with EUROVENT, AHRI (ARI-440-2008), and district cooling conditions.
Bespoke Solutions: Klima Global offers customized requirements to meet the unique HVAC demands of Saudi Arabia, UAE, and the wider Middle East.
Download the Technical Catalogue
Check out the air handling unit options suitable for your project.
Frequently Asked Questions (FAQs) – TALD Low Static Pressure FCU
Find answers below to the most common inquiries regarding the TAITECH TALD Low static pressure FCU series supplied by Klima Global across the GCC.
What are the primary applications for the TALD Low static pressure FCU?
The TALD series is specifically designed for the air conditioning of commercial buildings, such as hotel rooms and offices, where both cooling and heating are required.
What is the height of these units, and will they fit in shallow ceiling voids?
Yes, these units feature an “extra-flat” low profile of either 245mm or 295mm, making them ideal for installations with restricted ceiling space.
What cooling capacities and airflow ranges does the TALD series offer?
The series provides a cooling capacity ranging from 1.5 kW to 11 kW (sensible at medium speed) and an airflow range from 340 to 3400 m³/h.
Does Klima Global offer energy-efficient motor options for this Fan-Coil Unit?
Absolutely. While a built-in single-phase IP20 motor is standard, high-efficiency DC motor options are available to meet the energy-saving requirements of projects in the UAE and KSA.
Are these units suitable for high-humidity coastal environments like Qatar or Bahrain?
Yes. To withstand harsh conditions, we offer an optional RAL color powder coating for the structure to prevent rust, along with an optional double-skin casing for better insulation.
What are the benefits of the optional double-skin casing for the TALD series?
The double-skin casing is designed for projects requiring enhanced durability and thermal performance. It features a 0.5mm pre-painted outer layer and a 0.5mm inner layer, with high-density 40kg/m³ PE insulation sandwiched in between. This 25mm total thickness provides superior protection against high humidity and rust, which is essential for specialized HVAC projects across the Middle East.
